CYLINDRICAL UV PRINTER
Imported printhead + silent guide rail, 2880DPI ultra-high-definition image quality restores photo details; rotary printing supports cylindrical objects of different sizes and materials, including metal, glass, plastic and other cylindrical materials. It supports white ink, color ink and varnish printing, with rich colors and enhanced visual effects, meeting the customized printing needs of multiple scenarios and increasing product added value.
Main Features:
- High-precision printing
- Imported printhead
- Silent guide rail
- Instant drying
- High-speed printing
- Rotary printing
- High-precision servo motor
- White, Color & Varnish
Technical Specifications:
- Print Length:40–300 mm maximum printing length
- Printing Diameter:30–120 mm supported diameter range
- Printhead:DX7 / I3200HD professional printhead
- Print Resolution: Up to 2880 dpi high-definition printing
- Print Speed: 1–3 minutes per printing cycle
- Output Color: CMYK + White + Varnish configuration
- Ink Type:UV ink for durable printing
- Curing System: LED UV instant curing system
- Printing Method:Rotary printing for cylindrical products
- Special Effects: Relief and varnish finishing effects
Advanced Cylindrical Printing Technology. Precision Engineering. High-Performance Production.
Reliable Quality
Professional R&D team control, strict factory testing and excellent machine quality.
Source Factory
Factory direct sales, competitive pricing and flexible customization.
Fast Shipping
Multiple overseas warehouses and fast worldwide delivery support.
Complete Service System
Professional pre-sales, installation, training and after-sales support.
Key Features of Cylindrical UV Printer
360° Seamless Cylinder Printing
Achieve full-wrap printing on cans, cups, mugs, bottles, and tubes with smooth edge-to-edge graphics. The rotary printing system ensures precise alignment and high-quality results on cylindrical surfaces.
Direct Printing on Multiple Materials
Print directly on various cylindrical objects including metal cans, stainless steel tumblers, ceramic mugs, glass bottles, and plastic tubes. Perfect for personalized products and custom branding.
High-Resolution UV Printing
Deliver sharp images, vibrant colors, and fine details with advanced UV ink technology. The instant UV curing system provides durable prints with excellent scratch and fade resistance.
Rotary Precision Printing System
Equipped with an intelligent rotary mechanism that enables stable object rotation and accurate positioning for consistent cylindrical printing performance.
Product Specification
| Product Parameter | High-Speed Rotary Cylinder-Specific Printer |
| Print Length | 40–300 MM |
| Control Board | Self-contained Board Card |
| Printing Diameter | 30–120 MM |
| Spray Head Model | DX7 / I3200HD |
| Spray Head Speed | 1–3 MIN |
| Printhead Number | 1 |
| Print Taper | 0–8° |
| Print Quality | Resolution: 720 / 1440 / 2880 dpi |
| Output Color | CMYK + W + Varnish |
| Printing Technology | Variable Droplet Technology |
| Nozzle Heating | Bring Your Own (BYO) |
| Print Head | Epson Pro Print Head |
| Print Head Maintenance | Automatic / Manual Cleaning |
| Anti-Clog Printhead | Spray in Idle / Auto Agitation |
| Special Effects | Relief & Varnish |
| Ink Supply System | Full-Automatic Ink Supply System |
| Lifting Function | Platform Lifting |
| Transmission System | Imported Guide Rail + High-Precision Motor |
| Power Requirements | AC 220V / 110V, 50Hz–60Hz |
| Ink Characteristics | UV Ink |
| Operating System | Win7 / Win8 / Win10 |
| Curing System | LED UV |
| Interface Means | Gigabit Optical Fiber |
| Ink Level Monitoring | Multi-channel Real-time Out-of-ink Alarm |
| Output Software | Professional Output Software |
| File Format | JPG, PNG, PDF, TIF, EPS |
| Print Example | Various Cylindrical and Conical Products and Materials |
| Printing Method | Rotation Type |
| Operating Environment | Temperature: 15–35°C; Humidity: 20%–30% RH |
| Size | 1.23 × 0.73 × 0.86 M |
| Package Size | 131 × 96 × 115 CM |
| Package Weight | Approx. 224 KG |
Partner with PICTEL. Grow Faster. Earn More.
Your Success is Our Business.
We don't just supply machines we help you build a profitable printing business with the right products, expert guidance, marketing support, and dependable after-sales service.
- Higher Profit Potential
- Fast Service & Spare Parts
- Complete Business Support
- Long-Term Growth Partnership
- Trusted Engineering Expertise
Cylindrical UV Printer Application
Cans
Cups
Mugs
Tumblers
Bottles
Tubes
FAQ
It is designed for cylindrical and conical products and materials, using a rotary printing method.
The printer supports cylindrical products with diameters ranging from 30–120 mm.
It supports a printing length of 40–300 mm.
The printer uses one DX7 / I3200HD printhead with up to 2880 dpi resolution.
It uses UV ink and supports CMYK + White + Varnish output for enhanced printing effects.
Yes. The printer supports relief and varnish effects, with LED UV curing for the printed output.
